Overview
D3K2 Track-Type Tractor
| Engine Model | Cat C4.4 |
| Power - Net | 80.0 HP |
| Displacement | 269.0 in³ |
| Bore | 4.13 in |
| Stroke | 5.0 in |
| Note | Engine meets U.S. EPA Tier 4 Final emission standards. |
| Rated Net Power - 2,200 rpm - ISO 9249/EEC 80/1269 | 80.0 HP |
| Rated Net Power - 2,200 rpm - SAE J1349 | 80.0 HP |
Transmission
| Drive Pumps | 1 |
| Maximum Travel Speed - Forward | 5.6 mile/h |
| Maximum Travel Speed - Reverse | 6.2 mile/h |
| Relief Valve Settings | 7033.0 psi |
| Track Motors | 2 |
Weights
| Operating Weight - XL | 17465.0 lb |
| Operating Weight - LGP | 18442.0 lb |
| Note (1) | Specifications shown are for machine equipped with dozer blade, canopy ROPS, back-up alarm, operator, coolant, lubricants and full fuel tank. |
| Note (2) | Enclosed cab adds 225 kg (495 lb). |
| Operating Weight - LGP, 762 mm/30 in | 18896.0 lb |
Hydraulic Controls
| Pump Output | 17.7 gal/min |
| Relief Valve Settings | 2988.0 psi |
Undercarriage
| Ground Contact Area - LGP | 4425.0 in² |
| Ground Contact Area - LGP, 762 mm (30 in) | 5340.0 in² |
| Ground Contact Area - XL | 2829.0 in² |
| Ground Pressure - LGP | 4.2 psi |
| Ground Pressure - LGP, 762 mm (30 in) | 3.6 psi |
| Ground Pressure - XL | 6.2 psi |
| Length - Track on Ground - LGP | 89.0 in |
| Length - Track on Ground - XL | 89.0 in |
| Shoe Width - LGP | 25.0 in |
| Shoe Width - XL | 16.0 in |
| Track Gauge - LGP | 68.0 in |
| Track Gauge - LGP, 762 mm (30 in) | 73.0 in |
| Track Gauge - XL | 59.0 in |
| Length - Track on Ground - LGP, 762 mm (30 in) | 89.0 in |
| Number of Rollers - Each Side | 6 |
| Number of Shoes - Each Side - Sealed and Lubricated Track (SALT) Undercarriage | 43 |
| Number of Shoes - Each Side - SystemOne Undercarriage | 38 |
| Shoe Width - LGP, 762 mm (30 in) | 30.0 in |
