Be the solution you’re searching for as you power through obstacles in your path and adapt to the conditions at hand in the Kubota SVL97-2. Rugged terrain? No problem. The SVL97-2 and its 96.4 horsepower are ready to move ground and make sure you’re working in comfort and in confidence. Factor in its dominant tipping load, breakout force and advanced hydraulic system and we think you and the SVL97-2 are going to get along nicely. A workhorse, a go-getter, a friend-- the Kubota SVL97-2.
SPECIFICATIONS
- Horsepower (gross) - 96.4 HP
- Displacement (cu. in.) - 230
- Overall Length - 154.6"
- Overall Height - 83.4"
- Overall Width - 77.2"
- Operating Weight lbs. (kg) 11299/11574
- Rated Operating Capacity (ROC) - 35% Tipping Load (lbs.): 3200
- Tipping Load (lbs.) - 9143
- Bucket Breakout Force (lbf.) - 7961
- Lift Arm Breakout Force (lbf.) 5530
- Lift Arm Path - Vertical
- Track Width (standard/wide) - 17.7"
- Ground Contact Pressure (psi) - 4.4
- Track Rollers (per side) - 5
- Track Ground Contact Length - 65.6"
- Traveling Speed: High (mph) - 7.3
- Traveling Speed: Low (mph) - 5.0
- Traction Force (lbs.) - 12178
- Ground Clearance (in.) - 11.5"
- Auxiliary Hydraulic Pressure (psi) - 3553
- Auxiliary Hydraulics Flow Rate (GPM) - 23.1/40
- Height to Hinge Pin - 128.6"
- Ground Pressure - Standard Track: 4.4 psi
