General Dimensions and Weights
- Length 94 in
- Width 35 in
- Height 49 in
- Weight - Engine Option One 1550 lbs
-
Engine - Option one
- Make and Model Kohler ECH740
- Number of Cylinders 2
- Gross Horsepower (Maximum) 25 hp
- Torque (Max) 42 ft-lb
- Fuel Tank Capacity 6.8 gal
- Max Fuel Consumption 2.4 gph
- Fuel Type Gas
- Air Cleaner 6 " (15.2 cm) 2-Stage dry
- Oil Filter Spin-on
- Recommended Oil Kohler oil or API CH4/SJ
- Oil Volume with Filter 2 qt
- Maximum Angle of Continuous Operation 25 deg
- Cooling Medium Air/oil
-
Cutterwheel System
- Cutterwheel Diameter without Teeth 16 in
- Cutterwheel Thickness .5 in
- Cutterwheel Speed 1110 rpm
- Cutterwheel Straight Line Dimension 35.5 in
- Cutterwheel Cut Above Ground 25 in
- Cutterwheel Cut Below Ground 12 in
- Tooth Description Yellow Jacket Cutter System
- Number of Teeth 16
- Number of Indexes 2
- Number of Pockets 16
- Reversible Pockets Yes
- Cutterwheel Guard Yes
- Chip Containment 2.2 cu ft
-
Cutterwheel Drive Components
- Lower Gearbox Hydraulic motor
-
Hydraulic System
- Tank capacity 9 gal
- Recommended Oil Type ISO 68
- System Type Open loop
- Filtration Method Inline return filter
- Pump Flow at Maximum RPM 16 gpm
- System relief pressure 2750 psi
- Flow Control Autosweep (option)
- Directional Control Standard
- Oil Cooler Yes. Fan-cooled
-
Electrical System
- System Voltage 12
- Battery 405
- Standard Gauges Hour meter/tach
- Switches Cutter wheel drive
- Controller Yes
-
Chassis
- Control Station Description Fixed-rear
-
Track Drive System
- Track Type Rubber 7 " (17.8 cm) width
- Track Width - Retracted 35 " (88.9 cm)
- Track Width - Extended 35 " (88.9 cm)
- Track Length on Ground 31.4 " (79.7 cm)
- Type of Idler Cast
- Number of Idlers 5
- Track Drive Pump Type Hydrostatic
- System Relief Pressure 2900 psi (200 bar)
- Pump Flow at Maximum RPM 11.4 gpm (43.1 L/min)
- Track Drive Motor Type Geroter
- Track Brake Type Hydrostatic
- High Speed Travel 3.2 mph
- Ground Bearing Pressure - Soft Ground 3.4 psi
